Inside QAtrial’s Architecture: A Technical Overview of the Latest Release

QAtrial v3.0.0 is a full-stack quality management platform built with React 19, Hono, PostgreSQL, and Prisma ORM. This article is a technical walkthrough of the architecture for developers, architects, and technical evaluators considering QAtrial for regulated environments.

The codebase comprises 130+ TypeScript source files and 25,000+ lines of code. It supports 12 languages, 10 industry verticals, and 37 countries. Everything runs from a single repository with dual deployment modes: standalone (browser-only with localStorage) and server (full PostgreSQL backend).

Architecture Overview

Browser (React 19)  -->  Hono Server (port 3001)  -->  PostgreSQL 16
     |                        |                            |
     |-- Vite dev server      |-- 60+ API endpoints       |-- 15 Prisma models
     |-- 14 code-split chunks |-- 21 route files          |-- Append-only audit log
     |-- 20 Zustand stores    |-- JWT auth middleware      |-- ACID transactions
     |-- TanStack Table v8    |-- RBAC permission checks   |-- Referential integrity
     |-- react-i18next        |-- Webhook dispatch         |
     |-- Recharts             |-- AI proxy                 |
                              |-- SSO (OIDC)               |
                              |-- Static file serving      |

The frontend communicates with the backend exclusively through REST API calls authenticated with Bearer tokens. An apiClient.ts wrapper injects the JWT access token into every request and handles token refresh transparently.

In standalone mode, the same React components write to Zustand stores backed by localStorage. This allows the frontend to function as a fully operational demo without any server infrastructure. The import/export system, AI panel, and setup wizard all detect the current mode and route operations accordingly.

The Road to React: The React.js 19 with Hooks in JavaScript Book (2025 Edition)

View Latest Price

As an affiliate, we earn on qualifying purchases.

As an affiliate, we earn on qualifying purchases.

Database Layer: 15 Prisma Models

The PostgreSQL schema is defined in server/prisma/schema.prisma using Prisma ORM v7. The 15 models cover every entity in the quality management domain:

Model	Purpose	Key Fields
User	Authentication and identity	email, passwordHash, role, orgId
Organization	Multi-tenant isolation	name, slug
Project	Quality project container	name, country, vertical, projectType, modules[], orgId
Requirement	Quality requirement	seqId (REQ-NNN), title, description, status, riskLevel, regulatoryRefs[], tags[]
Test	Test case	seqId (TST-NNN), title, description, status, linkedRequirements[]
CAPA	Corrective/preventive action	title, description, status (6-state lifecycle), rootCause, correctiveAction
Risk	Risk assessment	severity, likelihood, detectability, riskLevel (auto-calculated)
Evidence	File attachment	filename, path, entityType, entityId
Approval	Approval workflow record	entityType, entityId, status (pending/approved/rejected), reviewerId
Signature	Electronic signature	userId, meaning, reason, timestamp, passwordVerified
AuditLog	Append-only event log	userId, action (16 types), entityType, entityId, previousValue, newValue, reason
Webhook	Webhook configuration	url, secret, events[], enabled, lastTriggered, lastStatus
Integration	External connector config	type (jira/github), config (JSON), enabled, lastSyncAt
Session	Token management	userId, refreshToken, expiresAt
Setting	System configuration	key, value, orgId

Sequential IDs (REQ-001, TST-001) are auto-generated per project by querying the maximum existing sequence number and incrementing. This runs inside a transaction to prevent race conditions in multi-user environments.

Learn PostgreSQL: Use, manage, and build secure and scalable databases with PostgreSQL 16

View Latest Price

As an affiliate, we earn on qualifying purchases.

As an affiliate, we earn on qualifying purchases.

Authentication: JWT with Refresh Tokens

The auth system uses a dual-token approach:

1. Access token (24-hour expiry): Included as a Bearer token in every API request. Contains the user’s ID, email, role, and organization ID. Validated by the requireAuth middleware on every protected endpoint.
2. Refresh token (7-day expiry): Stored client-side and used to obtain a new access token when the current one expires. The POST /api/auth/refresh endpoint validates the refresh token against the Session table and issues a new token pair.

Password hashing uses bcrypt with 12 rounds. The auth routes (server/routes/auth.ts) handle:

• POST /api/auth/register — Create user account, hash password, assign default role, return token pair.
• POST /api/auth/login — Validate credentials, return token pair.
• POST /api/auth/refresh — Exchange refresh token for new token pair.
• GET /api/auth/me — Return current user profile from JWT claims.

The requirePermission(permission) middleware chains after requireAuth and checks the user’s role against the permission matrix:

admin:        canView, canEdit, canApprove, canAdmin
qa_manager:   canView, canEdit, canApprove
qa_engineer:  canView, canEdit
auditor:      canView
reviewer:     canView, canApprove

Every mutation endpoint calls requirePermission('canEdit'). Approval endpoints call requirePermission('canApprove'). Administration endpoints call requirePermission('canAdmin'). View endpoints call requirePermission('canView').

TypeScript Programming Language – Software Engineer & Coder Pullover Hoodie

• Language Type: Superset of JavaScript with static typing
• Ideal Users: Front-end, full-stack developers, architects
• Application Scope: Builds large-scale web applications

View Latest Price

As an affiliate, we earn on qualifying purchases.

As an affiliate, we earn on qualifying purchases.

Template Composition System

QAtrial’s template system generates project-specific requirements and tests based on the combination of country, vertical, project type, and modules. The composition follows a layered architecture:

Country (jurisdiction)  x  Vertical (domain)  x  Project Type  x  Modules

Registry (src/templates/registry.ts): Central registry that indexes all available countries, verticals, modules, and project types.

Composer (src/templates/composer.ts): Takes the user’s selections from the setup wizard and composes the final set of requirements and tests. The composition process:

1. Load the base requirements for the selected country (regulatory authority, submission formats, local standards).
2. Overlay vertical-specific requirements (e.g., pharma adds ICH Q7/Q10, medical devices adds ISO 13485/ISO 14971).
3. Add module-specific requirements for each selected quality module.
4. Filter by project type (validation projects get different templates than quality system projects).
5. Generate test cases linked to the composed requirements.

Lazy loading: Template data is loaded on demand. The 10 vertical definitions, 15 module definitions, and country overlays are not bundled into the initial page load. They are imported dynamically when the setup wizard reaches the relevant step.

Compliance Starter Packs (src/templates/packs/index.ts): Four pre-configured bundles that set country, vertical, project type, and modules simultaneously. These bypass the manual wizard steps for common regulatory frameworks:

• fda_csv: US + Software/IT + Validation + 7 modules (Part 11, GAMP 5 focus)
• eu_mdr: DE + Medical Devices + Quality System + 9 modules (ISO 13485 focus)
• fda_gmp: US + Pharma + Quality System + 10 modules (21 CFR 210/211 focus)
• iso_gdpr: DE + Software/IT + Compliance + 7 modules (ISO 27001/GDPR focus)

API FRESHWATER MASTER TEST KIT 800-Test Freshwater Aquarium Water Master Test Kit, White, Single, Multi-colored

• Kit Contents: Includes 800 tests, solutions, color card, and tubes
• Water Quality Monitoring: Helps prevent harmful water issues
• Vital Parameter Testing: Measures pH, high pH, ammonia, nitrite, nitrate

View Latest Price

As an affiliate, we earn on qualifying purchases.

As an affiliate, we earn on qualifying purchases.

AI System: 9 Prompts, Multi-Provider, Server-Side Proxy

The AI subsystem is architected for flexibility and security:

Provider abstraction (src/ai/provider.ts): A unified interface that supports Anthropic (Claude) and OpenAI-compatible APIs. The OpenAI-compatible mode works with OpenAI directly, OpenRouter (multi-model gateway), and Ollama (local inference). Provider configuration is stored per-organization.

9 prompt templates (src/ai/prompts/):

Prompt	Input	Output
generateTests	Requirement + context (country, vertical, standards, risk)	4-6 test cases with steps and expected results
riskClassification	Requirement text + vertical	Severity, likelihood, risk level with rationale
gapAnalysis	Project requirements + target standard	Covered/partial/missing clauses with remediation suggestions
capaSuggestion	Failed test details	Root cause analysis + corrective/preventive action proposals
executiveBrief	Project state	One-page C-level compliance summary
vsrReport	Project data	7-section Validation Summary Report
qmsrGap	Requirements	QMSR/ISO 13485 gap analysis (27 clauses)
reqExtraction	Source document text	Extracted requirements with metadata
qualityCheck	Requirement text	Issues: vagueness, untestability, ambiguity, incompleteness, duplicates, missing criteria

JSON Schema validation (src/ai/validation.ts): Every AI response is validated against an expected JSON schema. If validation fails, the system attempts automatic repair (re-parsing, extracting JSON from markdown code blocks). If repair fails, a retry is triggered with a more explicit prompt.

Provenance tracking: Every AI generation records the model used, parameters, token count, timestamp, and the ID of the human reviewer who accepted or modified the output. This creates an audit trail for AI-generated content, addressing regulatory expectations around AI output review.

Server-side proxy (server/routes/ai.ts):

• POST /api/ai/complete — Accepts a prompt and parameters, proxies the call to the configured LLM provider. API keys are read from server environment variables (AI_PROVIDER_KEY) and never sent to the client.
• GET /api/ai/providers — Returns provider configuration with keys redacted.
• POST /api/ai/providers/:id/test — Tests provider connectivity.

This architecture means the browser never holds an AI API key. For pharma and device companies with strict data governance policies, this is a prerequisite for AI adoption.

Webhook Dispatch

Webhook delivery is implemented as a fire-and-forget pattern in server/services/webhook.service.ts:

1. A mutation occurs (e.g., requirement updated).
2. The route handler calls the webhook service with the event type and payload.
3. The service queries all enabled webhooks that subscribe to this event type.
4. For each matching webhook, the service:
   a. Serializes the payload as JSON.
   b. Computes an HMAC-SHA256 signature using the webhook’s secret.
   c. Sends an HTTP POST with the payload and signature header.
   d. Records the delivery status (lastTriggered, lastStatus) in the Webhook model.
5. Delivery failures are logged but do not block the original operation.

The fire-and-forget pattern ensures that webhook delivery issues (slow receivers, network problems) do not impact the user’s experience or create data consistency issues.

SSO: OIDC Discovery + Authorization Code Flow

The SSO implementation (server/routes/sso.ts) follows the standard OIDC authorization code flow:

1. Discovery: On startup (or first SSO request), QAtrial fetches the IdP’s .well-known/openid-configuration to discover the authorization endpoint, token endpoint, and JWKS URI.
2. Authorization redirect: When a user clicks “Sign in with SSO,” the browser is redirected to the IdP’s authorization endpoint with the configured client ID and callback URL.
3. Callback: The IdP redirects back to /api/auth/sso/callback with an authorization code.
4. Token exchange: QAtrial exchanges the code for an ID token and access token using the client secret.
5. Auto-provisioning: If no QAtrial user exists for the IdP’s email claim, a new user is created with the configured default role (SSO_DEFAULT_ROLE).
6. JWT issuance: QAtrial issues its own JWT access/refresh token pair, and the user is logged in.

Supported IdPs: Okta, Azure AD/Entra ID, Auth0, Keycloak, Google Workspace. Any OIDC-compliant IdP should work with the standard configuration.

Docker: Multi-Stage Build

The Dockerfile uses a three-stage build:

Stage 1 — Frontend build: Node.js image, npm install, npm run build. Produces the dist/ directory with the compiled React application, code-split into 14 Vite chunks.

Stage 2 — Server build: Compiles the Hono server TypeScript. Generates the Prisma client.

Stage 3 — Runtime: Slim Node.js image. Copies only the compiled server, generated Prisma client, and built frontend assets. No dev dependencies, no source TypeScript.

The production server serves the dist/ directory as static files. API routes are served under /api/. This means the entire application — frontend, backend, and API — runs from a single process on a single port.

docker-compose.yml defines two services:

• app: The QAtrial container, port 3001, depends on db, environment variables from .env.
• db: PostgreSQL 16, health check with pg_isready, named volume qatrial-db-data.

Health checks ensure the database is fully ready before the application attempts to connect.

Audit Trail: Append-Only PostgreSQL

The audit service (server/services/audit.service.ts) writes to the AuditLog table on every state-changing operation. The service is called from every route handler that creates, updates, deletes, approves, signs, or otherwise modifies data.

Each audit log entry captures:

Field	Content
userId	The authenticated user’s ID (from JWT)
action	One of 16 action types: create, update, delete, approve, reject, sign, status_change, import, export, login, logout, link, unlink, upload, download, config_change
entityType	requirement, test, capa, risk, evidence, approval, signature, webhook, integration, user, project
entityId	The specific record’s ID
previousValue	JSON snapshot of the record before the change (null for creates)
newValue	JSON snapshot of the record after the change (null for deletes)
reason	Optional reason provided by the user (required for certain operations)
timestamp	Server-generated UTC timestamp
ipAddress	Request origin IP

The table is append-only by design. There is no update or delete endpoint for audit log entries. The GET /api/audit/:projectId endpoint provides read access with filtering and pagination. GET /api/audit/:projectId/export produces a CSV file for offline review.

Import/Export

CSV Import (server/routes/import.ts):

• POST /api/import/preview: Accepts a CSV file upload. Auto-detects the delimiter by sampling the first rows (supports comma, semicolon, tab). Returns: detected columns, sample data rows, and suggested column mapping based on header name similarity to QAtrial fields.
• POST /api/import/execute: Creates requirements or tests from the mapped data. Supports duplicate handling strategies: skip (by title match), overwrite (update existing), or create new. Each imported record is audit-logged.

CSV Export (server/routes/export.ts):

• GET /api/export/:projectId/csv?type=requirements|tests|all: Returns a UTF-8 BOM-encoded CSV file. The BOM ensures correct character rendering when the file is opened in Excel on Windows (a common pain point with CSV exports).

In standalone mode, the frontend generates CSV directly from Zustand stores without server involvement.

Code Splitting

Vite is configured with manual chunks in vite.config.ts to optimize the initial load:

14 chunks split the application by feature area:

• Core framework (React, React DOM)
• UI libraries (TanStack Table, Recharts, Lucide)
• State management (Zustand stores)
• Internationalization (react-i18next + locale data)
• AI system (prompts, provider, validation)
• Templates (verticals, modules, regions, packs)
• Dashboard components
• Wizard components
• Import/export
• Settings
• Audit components
• Report generation
• Connectors
• Shared utilities

Lazy-loaded routes ensure that a user who opens only the requirements table does not download the AI prompt templates, report generators, or settings components until they navigate to those features.

Dual Mode: Standalone + Server

The same React codebase supports two operational modes:

Standalone mode: All data stored in browser localStorage via Zustand stores with persistence middleware. The 20 Zustand stores cover: projects, requirements, tests, CAPAs, risks, evidence, approvals, signatures, audit trail, settings, AI configuration, import state, wizard state, dashboard state, notifications, theme, language, auth (mock), connectors, and webhooks.

Server mode: All data operations go through the REST API. The apiClient.ts wrapper handles authentication, token refresh, and error handling. Zustand stores are still used for client-side state (current selection, UI state, cached data) but are not the source of truth.

Mode detection is automatic. If the frontend detects a configured VITE_API_URL and can reach the /api/status endpoint, it operates in server mode. Otherwise, it falls back to standalone mode.

This dual-mode architecture enables:

• Zero-setup demos and evaluations (standalone)
• Production deployment with full persistence, multi-user support, and audit compliance (server)
• Development without running the backend (standalone)
• Gradual migration from evaluation to production without data restructuring

Build and Development

Command	Description
npm run dev	Vite dev server (frontend only, port 5173)
npm run build	Production build (frontend)
npm run server:dev	Hono server with file watching (port 3001)
npm run server	Hono server without watching
npm run db:generate	Generate Prisma client from schema
npm run db:migrate	Run Prisma migrations
npm run db:push	Push schema directly to database
npm run db:studio	Open Prisma Studio GUI
docker-compose up	Start full stack (app + PostgreSQL)

Codebase Statistics

Metric	Value
Source files	130+
Lines of code	25,000+
Languages (i18n)	12 (425+ translation keys each)
Industry verticals	10
Countries	37
Database models	15
API endpoints	60+
Route files	21
AI prompt templates	9
Zustand stores	20
Vite chunks	14
Quality modules	15
Compliance packs	4
Validation documents	5
Webhook events	14
Audit action types	16
RBAC roles	5

Conclusion

QAtrial v3.0.0 is a complete quality management system, not a prototype or proof of concept. The architecture — React 19 frontend, Hono backend, PostgreSQL database, Prisma ORM, JWT authentication, five-role RBAC, append-only audit trail, OIDC SSO, webhook dispatch, and Docker deployment — addresses the technical requirements of regulated environments while remaining accessible to a single developer with docker-compose up.

The source code is available under AGPL-3.0 at https://github.com/MeyerThorsten/QAtrial.
